FR4 Flanged Bearing | Open / ZZ / 2RS | High Stability Inch Flanged Bearing

FR4 flanged bearing, FR4 open bearing, FR4ZZ shielded bearing, FR4 2RS sealed bearing, large bore inch miniature flange bearing, high stability tiny flanged bearing for precision machinery

FR4 Seal Type Features And Applications

1. FR4 Open (No Shield)

The open-frame design eliminates structural obstruction, delivering ultra-low friction and superior heat dissipation for sustained high-speed rotation. It allows easy regreasing and routine maintenance to keep precision transmission clean and efficient. Ideal for fully enclosed, lubrication-controlled indoor precision equipment, this non-protective version is optimized for high-efficiency, low-resistance micro rotary applications in stable environments.

2. FR4ZZ Double Metal Shields

Equipped with non-contact double-sided steel shields, FR4ZZ effectively blocks dry dust, fine particles and floating debris. Pre-greased for maintenance-free operation, it retains excellent high-speed performance while providing reliable dust protection. Suited for dry workshops, miniature drive motors, optical instruments and model equipment, it is the cost-effective choice for daily industrial dust-proof scenarios without moisture exposure.

3. FR4-2RS Double Rubber Seals

Featuring flexible double-lip rubber seals, this version creates a fully enclosed internal cavity to block moisture, water splash, oil contamination and fine dust. It locks internal grease firmly to prevent dry-out and oxidation, greatly extending service life in variable environments. Slightly increased structural rigidity enhances running stability, making it ideal for semi-open workshops and long-running unattended miniature equipment.

Material Introduction And Industrial Usage

1. GCr15 Chrome Steel

High-hardness bearing steel with outstanding wear resistance and rigid structural stability, delivering excellent dynamic load capacity and smooth low-noise operation. It offers the best cost performance for standard industrial use, only limited by weak rust resistance in humid conditions. Widely used in inch-standard micro motors, automation transmission parts and conventional precision machinery.

2. 420 Stainless Steel

Magnetic hardenable stainless steel with reliable oxidation resistance and good mechanical toughness. It provides basic anti-rust protection at an economical cost, perfect for mildly humid indoor devices, household smart mini equipment and cost-sensitive anti-corrosion projects.

3. 440 Stainless Steel

Premium hardened stainless steel balancing high hardness, wear resistance and moderate corrosion resistance. It maintains stable operation under continuous micro-load cycles and is widely adopted for food machinery, precision medical devices and light salt spray industrial equipment.

4. 304 Stainless Steel

Non-magnetic food-grade stainless steel with excellent moisture and weak acid-base resistance. Washable and sterilizable, it meets hygienic standards for clean environments. Suitable for low-speed light-load operation, commonly used in food processing micro-equipment and sanitary medical auxiliary devices.

5. 316 Stainless Steel

Molybdenum-enhanced corrosion-resistant stainless steel, resistant to chloride, seawater and chemical erosion. Non-magnetic and durable in harsh environments, it is the top choice for marine micro devices, chemical instruments and high-grade medical disinfection equipment.

Core Advantages

• High Stability Upgraded Structure: Enlarged bore and optimized internal structure improve concentricity and load capacity, reducing rotary deviation and prolonging service life.

• Integrated Flange Positioning: One-piece outer flange simplifies installation, ensures accurate axial limit and improves overall assembly consistency.

• Multi-Scenario Compatibility: Multiple seal and material combinations adapt to dry, dusty, humid, hygienic and corrosive working conditions.

• Precision Low-Noise Operation: Fine polished raceway ensures smooth rotation, stable output and low vibration for high-precision miniature systems.
